High Performance Automotive Pressfit Diodes -

JP Pressfit Automotive Diode

Main Features
  • Pressfit Design
  • Compliance with AEC-Q101 automotive specifications and PPAP processes
  • Voltage: 20-1000V
  • Current: 25-50A
  • Specific Dimention for the use in Japan
  • High Precision

Product info

JP automotive diodes is an essential component installed in the alternator of internal combustion engine from Japanese manufacturers; it is the main power device to convert alternating current to direct current. Actron provides a wide range automotive diodes covering Japan model voltages & currents. Applied the mainstream Press-fit application and has been used by major Japanese tier 1s for its well-known reliability and consistency on quality. Our product meets AEC-Q101 qualifications and full PPAP process, the optimal choice between price and performance.

Model No. Current Voltage External Diameter
JL30P/N ~ JL50P/N 30A-50A 20-24V 11.75±0.03 mm11.92±0.03 mm
JD30P/N ~ JD50P/N 30A-50A 24-29V 11.75±0.03 mm11.92±0.03 mm
JE30P/N ~ JE50P/N 30A-50A 24-32V 11.75±0.03 mm11.92±0.03 mm
JC30P/N ~ JC50P/N 30A-50A 34-40V 11.75±0.03 mm11.92±0.03 mm
JF30P/N ~ JE50P/N 30A-50A 38-43V 11.75±0.03 mm11.92±0.03 mm
JV30P/N ~ JV50P/N 30A-50A 100-1000V 11.75±0.03 mm11.92±0.03 mm

Remarks: Value for reference only, test value and condition please refer to released datasheets.
